SIO06 - Vehicle Wakeup Unit - Overview

SIO06 product view

SIO06 is a remote and condition-based vehicle wake-up unit.

Features

  • 10/100MBit/s Ethernet Interface
  • Power Input 24...110V DC (nom) wide range
  • 4x Digital Inputs via 6-pin spring terminal; 12 V DC nom.
  • 2x Analog Inputs via 4-pin spring terminal each; Voltage (+/-10 V) or current (+/-20 mA) type
  • 2x Relay Outputs via 6-pin spring terminal; 110 VDC nom., 0.4 A
  • Remote management capability
  • EN 50155 qualified
  • Mountable on TH35 DIN Rail or Simatic Rail
  • TRDP sink to receive relay commands from the vehicle server.
  • TRDP source to publish analog/digital input status at a configurable update cycle.
  • Device management, configuration and monitoring via HTTPS REST interface.
  • Device metrics via HTTP Prometheus API.
  • Secure Boot and Flash Encryption
