SIO07 - Bitbus Sniffer - Overview

SIO07 product view

SIO07 is unit to record Bitbus traffic without affecting the bus.

Features

  • 10/100MBit/s Ethernet Interface
  • Power Input 24...110V DC (nom) wide range
  • 1x Bitbus Interface via D-Sub connector
    • Non reactive monitoring of Bitbus traffic
    • Filtering of specific addresses and lengths
  • 1x serial interface with RS232 or RS485-full-duplex or RS485-half-duplex
    • Virtual tty support using RFC2217
    • Appears as a standard tty device on Linux hosts
  • Remote management capability
  • EN 50155 qualified
  • Device metrics via HTTP Prometheus API.

SIO07 is an Io4Edge device, and therefore supports the features common to all Io4Edge devices.
